JL667A HPE Aruba Networking CX 6100 24G 4SFP+ Switch
Product image shows a 1U rack-mountable switch with 24 Gigabit Ethernet ports, 4 SFP+ uplink ports, LED status indicators, and HPE branding on the front panel
What's New
- 24-Port Gigabit Data-Only Switch: Provides 24 ports of 10/100/1000BASE-T for cost-effective data-only access layer deployments where PoE is not required
- 4-Port SFP+ Uplinks: Features 4 SFP+ ports supporting 1/10G speeds for flexible fiber uplink connectivity to distribution switches
- Entry-Level Enterprise Switching: Part of the CX 6100 series designed for enterprise branch offices and SMB networks requiring reliable wired access
- No Software Licensing: All software features included with hardware purchase; no subscriptions or licensing fees required
- Compact 1U Form Factor: Rack-mountable design with side-to-side airflow for optimal cooling in wiring closets
Product Overview
The HPE Aruba Networking CX 6100 JL667A is a 24-port Gigabit data-only switch from the CX 6100 series, designed for cost-effective access layer deployments where Power over Ethernet is not required. This switch is ideal for connecting desktop computers, printers, servers, and other wired endpoints in office environments.
The CX 6100 series is based on the Aruba ASIC architecture with the programmable AOS-CX operating system used across the entire Aruba CX portfolio for a consistent operator experience. This Layer 2 switch series features built-in high-speed uplinks to support bandwidth-intensive applications.
With robust QoS, support for static routing, and IPv6, the CX 6100 simplifies ownership with no software licensing requirements. The switch supports automated configuration and verification with Aruba NetEdit, and is software-defined ready with REST APIs for programmability.
Technical Specifications
| Specification | Details |
|---|
| Product Number | JL667A |
| Series | HPE Aruba CX 6100 Switch Series |
| Device Type | Managed Layer 2 Switch |
| Form Factor | 1U Rack-mountable |
| Ports | 24 x 10/100/1000BASE-T (RJ-45) |
| Uplink Ports | 4 x 1/10G SFP+ |
| PoE Support | None (data only) |
| Switching Capacity | 128 Gbps |
| Throughput | 95.2 Mpps |
| Power Consumption | 33 W typical |
| Dimensions (W x D x H) | 44.2 x 26.8 x 4.4 cm (17.4 x 10.6 x 1.7 in) |
| Weight | 3.8 kg (8.38 lb) |
| Management | Web GUI, CLI, Aruba Central, Aruba NetEdit, REST APIs |
| Features | Static routing, ACLs, QoS, sFlow, IPv6, VSF stacking |
| Warranty | Limited Lifetime Warranty |
Key Features
24-Port Gigabit Data-Only Connectivity
The JL667A provides 24 Gigabit Ethernet ports for reliable wired connectivity for desktop computers, printers, servers, and other network endpoints in data-only deployments.
4x SFP+ Uplink Ports
Four SFP+ ports support 1 Gigabit and 10 Gigabit speeds, providing flexible fiber uplink connectivity to distribution switches or core networks.
AOS-CX Operating System
Built on Aruba's programmable AOS-CX operating system, the switch delivers consistent operator experience with advanced monitoring and automation capabilities.
No Software Licensing
All software features are included with the hardware purchase, eliminating the complexity and cost of ongoing licensing fees.
Static Routing
Layer 3 Lite capabilities include static routing, enabling basic network segmentation without requiring upstream router resources.
Energy Efficient Design
Low power consumption of just 33W typical makes this switch an energy-efficient choice for data-only access layer deployments.
Deployment Scenarios
Data-Only Office Networks
Ideal for office environments where PoE is not required. The 24 ports provide ample connectivity for desktop computers, printers, and other wired endpoints.
Classroom and Lab Networks
Perfect for educational environments requiring reliable wired connectivity for student workstations and lab equipment.
Conference Room Connectivity
Supports wired connectivity for presentation systems, codecs, and collaboration devices in meeting spaces.
Small Business Core
Suitable for small businesses as a core switch connecting servers, workstations, and other network infrastructure.
